SEGMENT BALL VALVE

늘 기술개발을 생각하며,
최고의 제품을 만들기 위해 노력하는 세원브이엔이
SEGMENT BALL VALVE

사양

Model SOFT SW-SB
METAL SW-SBM
Working Fluid COG GAS, SLUDGE etc.
Pressure Rating JIS 10K, 20K / #150, #300
Working Temperature -20℃ ~ 550℃
Size '50A~300A / 2"~12"
Type Gear boxed or Pneumatic actuator, Hand operated
Connection JIS B 2220 FF,RF / ASME #150,300 RF FLANGED
 Materials Body : Cast steel, Stainless Steel or Forged steel
(SCPH2, A351-CF8, A351-CF8M etc.)
Seat : PTFE, RTFE,MR Seat, PCTFE, Metal
